BOIL-OFF-GAS MANAGEMENT.
Harnessing a rich history of delivering cryogenic solutions globally, Fabrum presents cutting-edge boil-off-gas management (BOGM) systems for liquid natural gas (LNG) and liquid hydrogen (LH2), tailored for diverse applications across industries that include aviation, mining, marine, and heavy vehicle road transport.
At the heart of these groundbreaking systems are high-efficiency reliquefiers, ensuring zero-loss storage of both liquid hydrogen and liquid natural gas. Our innovative approach facilitates seamless fuel storage, transportation, and trans-filling operations.
With unmatched reliability and performance our advanced liquid transfer and fuelling systems pave the way for sustainable energy solutions.
HRL100.
PRODUCT SPECIFICATIONS:
- Applications: Liquid Hydrogen
- Daily reliquefier capacity (kg): 100
- Reliquefaction pressure (barg): 2-7
- Turn-down available: Yes
- Minimum output (% of FS): 0
- Footprint: 1 x 20’ ISO container
- Nominal power consumption (kW): 65
- SEC for entire system (kWh/kg): 15
- Start up time: <1 hr
PTC330-LNG.
PRODUCT SPECIFICATIONS:
- Applications: Liquid Natural Gas
- Daily reliquefier capacity (kg): 230
- Reliquefaction pressure (barg): 8
- Turn-down available: Yes
- Minimum output (% of FS): –
- Footprint: 1.3 x 0.8 x 1.7 m
- Nominal power consumption (kW): 12
- SEC for entire system (kWh/kg): 1.5
- Start up time: <10 min
